Запчасти Komatsu PW160-8 ЗАДН. ОПОРА, ЦИЛИНДР ВНУТР. ЧАСТИ ЗАДН. ОПОРА

|$1

20G-61-31131

Cylinder Assembly

1

20E-62-K9570

Cylinder

2

20E-62-K9580

Piston Rod

3

20E-63-K5280

Piston

4

20E-63-K5290

Guide

5

20E-62-K9590

Control Spool

6

20E-62-K6190

Valve Seat

7

20G-61-31140

Relief Valve

8

20E-62-K6440

Valve Poppet

9

20E-62-K6450

Screw Plug

10

20E-63-K5380

Bearing

11

20E-63-K5390

Circlip

12

20E-63-K5410

Grease Nipple

13

20E-63-K5110

Wiper, (Kit : K07)

14

20E-63-K5120

Ring, (Kit : K07)

15

20E-63-K5130

Rod Wear Ring, (Kit : K07)

16

20E-63-K5140

O-Ring, (Kit : K07)

17

20E-63-K5150

Back-Up Ring, (Kit : K07)

18

20E-63-K5160

O-Ring, (Kit : K07)

19

20E-63-K5170

Ring, (Kit : K07)

20

20E-63-K5180

O-Ring, (Kit : K07)

21

20E-63-K5190

Back-Up Ring, (Kit : K07)

22

20E-63-K5210

Piston Wear Ring, (Kit : K07)

23

20E-63-K5220

O-Ring, (Kit : K07)

24

20E-63-K5230

Back Up Ring, (Kit : K07)

25

20E-62-K6630

O-Ring, (Kit : K07)

26

20E-61-K2450

Back-Up Ring, (Kit : K07)

27

20E-62-K6640

O-Ring, (Kit : K07)

28

20E-62-K6670

Pressure Spring

29

20E-63-K5360

Groove Nut

30

20E-63-K5370

Screw
