Запчасти Komatsu PW160-8 ЗАДН. ОПОРА ЗАДН. ОПОРА

1

20G-910-4290

Frame Assembly

2

20K-910-4210

Cover

3

01010-80825

Bolt

4

01643-30823

Washer

5

01010-82060

Bolt

6

01643-32060

Washer

|$7

20G-910-3713

Leg Assembly

8

203-70-56130

Bushing

9

07145-00070

Seal

10

20G-47-13180

Bushing

11

07145-00045

Seal, Dust

12

07020-00000

Fitting, Grease

13

20E-47-K1560

Pin

14

04052-11664

Pin

15

01641-21626

Washer

16

20G-61-31131

Cylinder Assembly

17

02782-10315

Elbow

18

02782-10316

Elbow

19

02896-61009

O-Ring

20

07002-62034

O-Ring

21

20E-61-K2581

Plate

22

01010-81020

Bolt

23

01643-31032

Washer

24

20G-910-3811

Foot

25

20G-910-4180

Foot

26

20G-910-3861

Pin

27

20K-910-3841

Pin

28

20K-910-3851

Pin

29

20E-47-K1430

Pin

30

01010-81016

Bolt

31

144-854-1890

Washer

32

01253-41210

Bolt

33

01641-21223

Washer

34

07020-00000

Fitting, Grease

35

01010-81016

Bolt

36

01010-81016

Bolt

37

144-854-1890

Washer

38

144-854-1890

Washer

39

01220-40516

Screw

40

20G-47-K1690

Reflector
