Запчасти Komatsu PW160-8 МОТОР ХОДА, ВНУТР. ЧАСТИ (/) МОТОР ХОДА

|$1

20G-60-31102

Travel Motor

|$2

20K-60-31850

End Cover Sub Assembly

|$3

20K-60-32370

Valve Assembly

1

20K-60-32580

Poppet, Valve

2

20K-60-32590

Spring

3

20K-60-32610

Seat

4

20K-60-32620

Poppet, Valve

5

20K-60-32630

Spring

6

20K-60-32640

Screw

7

20K-60-32650

O-Ring

|$11

20K-60-32380

Shuttle Valve A.

8

20K-60-32660

Screw, Valve

9

20K-60-32670

Ball

10

20K-60-32680

Bushing

|$15

20K-60-32390

Piston Assembly, Brake

11

20K-60-32690

Piston, Brake

12

20K-60-32710

Bushing, Valve

13

20K-60-32720

Pin, Throttle

14

20K-60-32730

Screw, Valve

15

20K-60-32740

Bolt

16

20K-60-32750

Collar

17

20K-60-32760

Screw

18

20K-60-32770

Spring

19

20K-60-32780

Orifice

|$25

20K-60-32410

Check Valve Assembly

20

20K-60-32790

Housing, Valve

21

20K-60-32810

Housing, Valve

22

20K-60-32820

Piston, Valve

23

20K-60-32830

Spring

24

20K-60-32840

O-Ring

25

20K-60-32850

Ring, Back-Up

26

20K-60-32420

Housing

27

20K-60-32430

Cover

28

20K-60-32440

Cover

29

20K-60-32450

Screw

30

20K-60-32460

Screw

31

20K-60-32470

Plug

32

20K-60-32480

O-Ring

33

20G-60-K5020

O-Ring

34

20K-60-32510

O-Ring

35

20K-60-32520

Screw

36

20K-60-32530

Screw

37

20G-60-K2750

Pin

38

20K-60-32550

Screw

39

20K-60-32560

Screw
