Запчасти Komatsu PW160-8 ВЕРХН. ЧАСТЬ, КАБИНА ВЕРХН. ЧАСТЬ

1

20G-54-31842

Top Cover, RHS

2

20Y-54-27531

Lock Assembly, Welded

3

20Y-54-27540

Lock

4

130-955-1960

Pin

5

20Y-54-27560

Spring

6

04050-13020

Pin, Cotter

|$7

20Y-54-75900

Lock Assembly

7

20Y-54-75930

Bracket

8

04205-11038

Pin

9

04050-13020

Pin, Cotter

10

20Y-54-75910

Plate

11

21K-22-26351

Spring

12

20Y-54-75920

Plate

13

20X-54-21460

Spring

14

01010-81025

Bolt

15

01643-31032

Washer

16

20G-54-32370

Plate

17

20G-54-32360

Plate

18

01010-81225

Bolt

19

01643-31232

Washer

20

205-54-68440

Plate

21

01224-40616

Screw

22

01010-81225

Bolt

23

01643-31232

Washer

24

20G-54-41140

Frame, Rear, LHS

25

20G-54-33911

Partition
