Запчасти Komatsu PW160-8 КАБИНА И ОСНОВН. КОНСТРУКЦИЯ ГРУППА, ПОЛ, КОНСОЛЬ, RHS, ПЕРЕКЛЮЧАТЕЛЬES КАБИНА И ОСНОВН. КОНСТРУКЦИЯ ГРУППА

1

08086-20000

Switch, Starting

2

20Y-43-41740

Plate

3

20Y-43-41750

Washer

4

20Y-43-41790

Washer

5

20Y-43-41671

Sheet

6

08034-20519

Band

7

22U-06-22380

Potentiometer

8

22U-06-22460

Spring

9

20Y-43-41780

Knob

10

20Y-06-42110

Switch, Swing Lock

11

426-06-33490

Switch, Parking Brake

12

418-06-46130

Switch, Hazard Warning

13

20G-06-41140

Wiring Harness

14

08034-20414

Band

15

01023-10508

Screw

16

01601-20513

Ring, Spring

17

22U-43-23260

Clip

18

04435-51910

Clip

19

01010-81016

Bolt

20

01643-31032

Washer

21

04434-51410

Clip

22

01010-81016

Bolt

23

01643-31032

Washer

24

423-06-45360

Switch, Front Worklamps

24

17A-06-42230

Switch, Worklamps

25

20Y-43-41880

Cover

26

01245-00616

Screw

27

01643-70623

Washer

28

20Y-53-12310

Collar

29

20Y-43-41372

Bracket

30

20Y-06-42150

Switch, Lower Wiper

31

20Y-06-42160

Switch, Heated Seat

32

20K-06-41280

Switch, Auto Grease

33

20K-06-41310

Switch, Quick Coupler

34

20Y-06-42130

Switch, Quick Coupler

35

20Y-06-42190

Cover

36

423-06-45350

Switch, Rear Worklamps

36

17A-06-42230

Switch, Worklamps
