Запчасти Komatsu PW160-8 МАСЛООХЛАДИТЕЛЬ, РАДИАТОР И ПОДАЧА МАСЛООХЛАДИТЕЛЬ МАСЛООХЛАДИТЕЛЬ

|$1

20G-03-31540

Cooler Assembly

1

175-54-88110

Washer

2

01010-81016

Bolt

3

01010-81020

Bolt

4

01010-81025

Bolt

5

01010-81030

Bolt

6

01010-81060

Bolt

7

01597-01009

Nut

8

01643-31032

Washer

9

01643-51032

Washer

10

07000-13035

O-Ring

11

07283-33442

Clip

12

20G-03-31550

Sheet

13

20G-03-31560

Sheet

14

20G-03-31570

Sheet

15

20G-03-31580

Sheet

16

20G-03-32111

Tube

17

20G-03-32120

Tube

18

20G-03-32130

Oil Cooler

19

20G-03-32140

Radiator

20

20G-03-32150

Charge Oil Cooler

21

20G-03-32160

Top Plate

22

20G-03-32170

Bottom Plate

23

20G-03-32180

Fan Shroud

24

20G-03-32190

Adjustment Ring

25

20G-03-32210

Seal

26

20G-03-32220

Bracket

27

20G-03-32230

Bracket

28

20G-03-32240

Bracket

29

20G-03-32260

Cap

30

20G-03-32270

Bracket

31

20G-03-32270

Bracket

32

20G-03-32280

Seal

33

20G-03-32280

Seal

34

20K-03-31910

Valve

35

07287-00807

Hose

36

07285-00125

Clip
