Запчасти Komatsu PW160-8 OPERATORґS СИДЕНЬЕ, МЕХАНИЧ. ПОДВЕСКА, ВНУТР. ЧАСТИ (/) OPERATORґS СИДЕНЬЕ, МЕХАНИЧ. ПОДВЕСКА

|$1

20E-57-41151

Seat, Mechanical Suspension

|$2

20K-57-31151

Seat Assembly

1

20K-57-31180

Seat

2

20K-57-31190

Seat

3

20K-57-31410

Screw

4

20K-57-31210

Nut

5

20K-57-31220

Screw

6

20K-57-31440

Rest

7

20K-57-31460

Washer

8

20K-57-31470

Screw

9

20K-57-31230

Rod

10

20K-57-31480

Rivet

11

20K-57-31240

Plate

12

20K-57-32210

Screw

13

20K-57-31490

Washer

14

20K-57-31560

Plate

15

20K-57-31570

Rivet

16

20K-57-31580

Sheet

17

20K-57-31590

Block

18

20K-57-31610

Box

19

20K-57-31620

Cover Kit

20

20K-57-31630

Bracket Kit

21

20K-57-31640

Rivet

22

20K-57-31650

Washer

23

20K-57-33340

Cover LHS

24

20K-57-31670

Bearing

25

20K-57-31680

Spring

26

20K-57-31690

Plate

27

20K-57-31710

Screw

28

20K-57-31720

Screw

29

20K-57-31730

Nut

30

20K-57-31740

Lever

31

20K-57-31750

Handle

32

20K-57-31760

Plate

33

20K-57-31770

Screw

34

20K-57-33350

Cover RHS

35

20K-57-31790

Seat

36

20K-57-31810

Sheet

37

20K-57-31820

Latch

38

20K-57-31830

Cover

39

20K-57-31840

Handle

40

20K-57-31850

Handle

41

20K-57-31260

Rest

42

20K-57-31870

Bushing

43

20K-57-31270

Support

44

20K-57-31280

Screw

45

20K-57-31290

Handle

46

20K-57-31310

Wheel

47

20K-57-31320

Rivet

48

20K-57-31330

Brake

49

20K-57-31340

Carrier

50

20K-57-31890

Screw

51

20K-57-31910

Rivet

52

20K-57-33320

Cover

53

20K-57-31930

Rod

54

20K-57-31940

Spring

55

20K-57-31950

Bushing

56

20K-57-31960

Screw

57

20K-57-31970

Lever

58

20K-57-33360

Arm Rest RHS

59

20K-57-33370

Arm Rest LHS

60

20K-57-31350

Rail Kit

61

20K-57-32120

Screw

62

20K-57-32130

Screw

63

20K-57-31360

Bracket

64

20K-57-32140

Seat Belt Kit

65

20K-57-31370

Nut

66

20E-57-41140

Plate

67

02215-10710

Nut

68

02030-70738

Bolt

69

02030-70729

Bolt

70

424-00-H0280

Protection Cap
