Запчасти Komatsu PW160-7K ГИДР. БАК. ГИДРАВЛИКА
№
Артикул
Название
Примечание
Количество
1
01010-81020
BOLT
2
01010-81025
BOLT
3
01010-81230
BOLT
4
01643-31232
WASHER
5
01252-70516
BOLT
6
01580-31008
NUT
7
01601-20513
WASHER
8
01643-31032
WASHER
9
07002-12434
O-RING
10
07044-12412
PLUG
11
07270-61512
TUBE
12
07285-00155
CLIP
13
17A-60-11310
CAP ASS'Y
14
20Y-60-21470
ELEMENT
15
20G-54-33080
PLATE
16
20G-60-31352
TANK
17
20Y-54-14290
STOPPER
18
20Y-60-21240
SPRING
19
20Y-60-21340
GASKET
20
20Y-60-21460
NECK
21
207-60-71180
ELEMENT
22
20Y-60-31131
VALVE ASS'Y
23
20Y-60-31140
STRAINER
|24
20Y-60-31171
STRAINER ASS'Y
24
207-60-61150
ROD ASS'Y
25
20Y-60-21320
HOLDER
26
12R-60-11230
SPRING
27
22B-60-11160
STRAINER
28
20Y-60-K1480
GAUGE
29
20G-60-31250
COVER
30
22U-60-21231
COVER
31
21P-54-K5430
PLATE
32
07000-15160
O-RING
33
07000-15195
O-RING
34
20K-62-31710
TEE
35
02896-11012
O-RING
36
02896-11009
O-RING
37
07002-12034
O-RING
38
02782-10315
ELBOW
39
02896-11009
O-RING
40
07002-12034
O-RING
41
02782-10317
ELBOW
42
02896-11009
O-RING
43
07002-12034
O-RING
44
02782-10424
ELBOW
45
02896-11012
O-RING
46
07002-12034
O-RING
47
02781-00422
UNION
48
02896-11012
O-RING
49
07002-12034
O-RING
50
02782-10628
ELBOW
51
02896-11018
O-RING
52
07002-12434
O-RING
53
02781-00315
UNION
54
02896-11009
O-RING
55
07002-12034
O-RING
56
02782-10425
ELBOW
57
02896-11012
O-RING
58
07002-12434
O-RING
59
01010-81635
BOLT
60
01643-31645
WASHER
61
195-03-11570
SHIM¤ 1.0MM
62
20G-60-31560
SHEET
63
20G-60-31570
SHEET
64
20G-60-31580
SHEET
65
20G-60-31590
SHEET
66
20G-60-31610
SHEET
Выбрано товаров: 67
