Запчасти Komatsu PW160-7K МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

20K-60-31850

END COVER SUB ASS'Y

|1

20K-60-32370

VALVE ASS'Y

1

20K-60-32580

POPPET,VALVE

2

20K-60-32590

SPRING

3

20K-60-32610

SEAT

4

20K-60-32620

POPPET,VALVE

5

20K-60-32630

SPRING

6

20K-60-32640

SCREW

7

20K-60-32650

O-RING

|8

20K-60-32380

SHUTTLE VALVE A.

8

20K-60-32660

SCREW,VALVE

9

20K-60-32670

BALL

10

20K-60-32680

BUSHING

|11

20K-60-32390

PISTON ASS'Y,BRAKE

11

20K-60-32690

PISTON,BRAKE

12

20K-60-32710

BUSHING,VALVE

13

20K-60-32720

PIN,THROTTLE

14

20K-60-32730

SCREW,VALVE

15

20K-60-32740

BOLT

16

20K-60-32750

COLLAR

17

20K-60-32760

SCREW

18

20K-60-32770

SPRING

19

20K-60-32780

ORIFICE

|20

20K-60-32410

CHECK VALVE ASS'Y

20

20K-60-32790

HOUSING,VALVE

21

20K-60-32810

HOUSING,VALVE

22

20K-60-32820

PISTON,VALVE

23

20K-60-32830

SPRING

24

20K-60-32840

O-RING

25

20K-60-32850

RING,BACK-UP

26

20K-60-32420

HOUSING

27

20K-60-32430

COVER

28

20K-60-32440

COVER

29

20K-60-32450

SCREW

30

20K-60-32460

SCREW

31

20K-60-32470

PLUG

32

20K-60-32480

O-RING

33

20K-60-32490

O-RING

34

20K-60-32510

O-RING

35

20K-60-32520

SCREW

36

20K-60-32530

SCREW

37

20K-60-32540

PIN

38

20K-60-32550

SCREW

39

20K-60-32560

SCREW
