Запчасти Komatsu PW160-7K МОТОР ХОДА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

20G-60-31101

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1641-01A0 TO Y1641-05A0.

|1

20G-60-31660

CONTROL ASS'Y

1

20E-60-K4520

HOUSING,CONTROL

2

20G-60-K2640

BUSHING,CONTROL

3

20K-20-32290

PISTON,CONTROL

4

20G-60-K4920

BUSHING,ADJUSTING

5

20K-60-32310

COLLAR

6

20G-60-31710

COLLAR

7

20G-60-K4290

SPRING

8

20G-60-31720

SPRING

9

20E-60-K4580

SPRING

10

20G-60-K4940

O-RING

11

20G-60-K4950

SCREW

12

20G-60-K4320

SCREW

13

20G-60-K2730

RING,RETAINING

14

20G-60-K1490

STUD

15

20G-60-K4960

PIN

16

20G-60-K1520

NUT,LOCK

17

20G-60-K2750

PIN

18

20G-60-K2590

PIN

19

20G-60-K2760

DISC,RETAINING

|20

20G-60-31670

COVER ASS'Y

20

20G-60-K4970

COVER

21

20K-60-32340

SCREW

22

20E-60-K5010

SCREW

23

20G-60-K5020

O-RING

24

20G-60-K4320

SCREW
