Запчасти Komatsu PW160-7K ПЕРЕДНИЙ МОСТ (/) (.M ШИР.) SUSPENTION И КОЛЕСА

|$1

20G-23-31001

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.S1150-51A0 TO S1150-56A0.

1

20G-23-31530

BODY,LONG

2

20G-23-31560

BODY,SHORT

3

20K-22-31270

PLUG

4

20K-22-31210

PLUG

5

20G-23-31570

SCREW

6

20G-23-31590

WASHER

7

20G-23-31610

O-RING

8

20K-23-31680

NIPPLE

|9

20G-23-32180

PIN ASS'Y

9

20G-23-31630

PIN

10

20K-23-31680

NIPPLE

11

20K-23-31310

CAP,PROTECTION

12

20K-23-31720

BUSHING

13

20G-23-31650

RING

14

20G-23-31660

WASHER

15

20G-23-31580

VALVE,PRESSURE

16

20K-23-31580

BUSHING

17

20G-23-31670

VALVE,AIR

18

20G-23-31680

SEAL

19

20G-23-31690

RING,SEAL

20

20K-23-31760

O-RING

21

20K-23-31770

SCREW

22

20G-23-31710

PIN,DOWEL

23

20K-23-31790

DOWEL,SECURITY

24

20K-23-31310

CAP,PROTECTION
