Запчасти Komatsu PW160-7K ПЕРЕДНИЙ МОСТ (/) (.M ШИР.) SUSPENTION И КОЛЕСА

Схема запчастей Komatsu PW160-7K - ПЕРЕДНИЙ МОСТ (/) (.M ШИР.) SUSPENTION И КОЛЕСА
14
5
9
13
24
7
21
10
8
12
11
15
1
6
20
16
18
17
23
3
22
11
2
4
19

Артикул

Название

Примечание

Количество

|$1

20G-23-31001

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.S1150-51A0 TO S1150-56A0.

1

20G-23-31350

PLANETARY ASS'Y

2

20K-22-31440

O-RING

3

20G-23-31380

SHIM¤

4

20G-23-31390

HUB

5

20G-23-31410

SHAFT ASS'Y

6

20K-22-31230

WHEEL

7

20G-23-31420

BOX,JOINT

8

20K-23-31570

RING

9

20G-23-31430

BUSHING

10

20G-23-31440

DISK, WASHER

11

20G-23-31450

BEARING,ROLLER

12

20K-22-31310

GASKET

13

20G-23-31460

SEAL

14

20G-23-31470

PLUG

15

20K-22-31280

SCREW, PLUG

16

20K-22-31380

SCREW

17

20K-22-31260

BUSHING

18

20K-22-31250

WASHER

19

20K-22-31390

SCREW

20

20K-22-31240

CIRCLIP

21

20K-23-31620

CIRCLIP

22

20G-23-31480

SHIM¤

23

20G-23-31490

RING,ADJUSTING

24

20G-23-31510

BLEEDER

Выбрано товаров: 25
