Запчасти Komatsu PW160-7K ПЕРЕДНИЙ МОСТ (/) (.M ШИР.) SUSPENTION И КОЛЕСА

|$1

20G-23-31001

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.S1150-51A0 TO S1150-64A0.

1

20G-23-31330

SHIM

2

20G-22-31340

SHIM

3

20G-23-31180

ROD,CONNECTING

|4

20K-23-32170

TIE ROD ASS'Y

4

20K-23-31990

TIE ROD

5

20K-23-31280

BEARING

6

20K-23-31290

NIPPLE

7

20K-23-31310

CAP,PROTECTION

8

20G-23-31160

COVER

9

20G-23-31190

BUSHING

10

20G-23-31170

HOSE,CYLINDER

11

20G-23-31260

FORK

12

20G-23-31270

PIN

13

20G-23-31290

O-RING

14

20G-23-31240

GASKET,PISTON

15

20G-23-31210

EXTRACTOR

16

20G-23-31220

SEAL ,PISTON ROD

17

20G-23-31230

O-RING

18

20G-23-31280

O-RING

19

20G-23-31310

SCREW

20

20G-23-31940

SCREW

21

20K-23-31450

PIN,SNAP

22

20K-23-31460

WASHER

23

20G-23-31320

WASHER

24

20K-23-31480

PLUG

25

20G-23-31250

GUIDE RING

26

20K-23-31510

NUT

27

20K-23-31520

SCREW
