Запчасти Komatsu PW160-7E0 ЦИЛИНДР ОТВАЛА (ВНУТР. ЧАСТИ) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

20G-61-31121

CYLINDER ASSEMBLY

1

20K-62-38140

CYLINDER

2

20K-62-38120

PISTON ROD

3

20E-62-K6170

PISTON

4

20K-62-38130

GUIDE

5

20K-61-31520

SPOOL

6

20K-61-31510

SEAT

7

20K-61-31490

SEAT

8

20K-61-31480

POPPET

9

20K-61-31470

BOLT

10

20K-61-31460

PLUG

11

20K-61-31450

PLUG

12

20K-61-31260

SPRING

13

20K-61-31440

WIPER (KIT)

14

20K-61-31430

O-RING (KIT)

15

20K-61-31420

RING (KIT)

16

20E-62-K6580

O-RING (KIT)

17

20E-62-K6590

BACK-UP RING (KIT)

18

20E-62-K6610

O-RING (KIT)

19

20E-62-K6530

RING (KIT)

20

20E-62-K6540

O-RING (KIT)

21

20E-62-K6550

BACK-UP RING (KIT)

22

20E-62-K6560

PISTON RING (KIT)

23

20K-61-31330

O-RING (KIT)

24

20K-61-31320

RING (KIT)

25

20K-61-31310

O-RING (KIT)

26

20K-61-31290

RING (KIT)

27

20K-61-31280

O-RING (KIT)

28

20K-61-31270

SPRING

29

20K-61-31250

NUT

30

20K-61-31240

SCREW

31

20K-61-31230

BEARING

32

20K-61-31220

NIPPLE

KIT

20G-61-H0P01

SEAL KIT
