Запчасти Komatsu PW160-7E0 МОТОР ХОДА (ВНУТР. ЧАСТИ /) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PW160-7E0 - МОТОР ХОДА (ВНУТР. ЧАСТИ /) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
a
a
38
27
32
15
13
12
16
18
16
11
19
17
12
13
14
39
28
32
34
33
26
33
10
9
8
36
21
22
23
20
24
25
6
7
5
4
3
2
1
29
31
36
30
37
35
1
2
3
4
5
7
6
21
22
23
20
24
25

Артикул

Название

Примечание

Количество

|$1

20G-60-31102

TRAVEL MOTOR

|$2

20K-60-31850

END COVER SUB ASSEMBLY

|$3

20K-60-32370

VALVE ASSEMBLY

1

20K-60-32580

POPPET, VALVE

2

20K-60-32590

SPRING

3

20K-60-32610

SEAT

4

20K-60-32620

POPPET, VALVE

5

20K-60-32630

SPRING

6

20K-60-32640

SCREW

7

20K-60-32650

O-RING

|$11

20K-60-32380

SHUTTLE VALVE A.

8

20K-60-32660

SCREW, VALVE

9

20K-60-32670

BALL

10

20K-60-32680

BUSHING

|$15

20K-60-32390

PISTON ASSEMBLY, BRAKE

11

20K-60-32690

PISTON, BRAKE

12

20K-60-32710

BUSHING, VALVE

13

20K-60-32720

PIN, THROTTLE

14

20K-60-32730

SCREW, VALVE

15

20K-60-32740

BOLT

16

20K-60-32750

COLLAR

17

20K-60-32760

SCREW

18

20K-60-32770

SPRING

19

20K-60-32780

ORIFICE

|$25

20K-60-32410

CHECK VALVE ASSEMBLY

20

20K-60-32790

HOUSING, VALVE

21

20K-60-32810

HOUSING, VALVE

22

20K-60-32820

PISTON, VALVE

23

20K-60-32830

SPRING

24

20K-60-32840

O-RING

25

20K-60-32850

RING, BACK-UP

26

20K-60-32420

HOUSING

27

20K-60-32430

COVER

28

20K-60-32440

COVER

29

20K-60-32450

SCREW

30

20K-60-32460

SCREW

31

20K-60-32470

PLUG

32

20K-60-32480

O-RING

33

20G-60-K5020

O-RING

34

20K-60-32510

O-RING

35

20K-60-32520

SCREW

36

20K-60-32530

SCREW

37

20G-60-K2750

PIN

38

20K-60-32550

SCREW

39

20K-60-32560

SCREW

Выбрано товаров: 45
