Запчасти Komatsu PW160-7E0 МАСЛООХЛАДИТЕЛЬ, РАДИАТОР И ПОДАЧА МАСЛООХЛАДИТЕЛЬ C СИСТЕМА ОХЛАЖДЕНИЯ

|$1

20G-03-31540

COOLER ASSEMBLY

1

175-54-88110

WASHER

2

01010-81016

BOLT

3

01010-81020

BOLT

4

01010-81025

BOLT

5

01010-81030

BOLT

6

01010-81060

BOLT

7

01597-01009

NUT

8

01643-31032

WASHER

9

01643-51032

WASHER

10

07000-13035

O-RING

11

07283-33442

CLIP

12

20G-03-31550

SHEET

13

20G-03-31560

SHEET

14

20G-03-31570

SHEET

15

20G-03-31580

SHEET

16

20G-03-32111

TUBE

17

20G-03-32120

TUBE

18

20G-03-32130

OIL COOLER

19

20G-03-32140

RADIATOR

20

20G-03-32150

CHARGE OIL COOLER

21

20G-03-32160

TOP PLATE

22

20G-03-32170

BOTTOM PLATE

23

20G-03-32180

FAN SHROUD

24

20G-03-32190

ADJUSTMENT RING

25

20G-03-32210

SEAL

26

20G-03-32220

BRACKET

27

20G-03-32230

BRACKET

28

20G-03-32240

BRACKET

29

20G-03-32260

CAP

30

20G-03-32270

BRACKET

31

20G-03-32270

BRACKET

32

20G-03-32280

SEAL

33

20G-03-32280

SEAL

34

20K-03-31910

VALVE

35

07287-00807

HOSE

36

07285-00125

CLIP
