Запчасти Komatsu PW160-7 ПЕРЕДНИЙ МОСТ (/) - КОЛЕСА ВТУЛКА ASSEMBLY С ТОРМОЗ. Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PW160-7 - ПЕРЕДНИЙ МОСТ (/) - КОЛЕСА ВТУЛКА ASSEMBLY С ТОРМОЗ. Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
7
14
15
4
8
3
5
9
2
10
1
6
8
11
12
13
20
16
17
18
21
38
38
22
30
18
37
23
36
24
29
39
25
26
34
27
33
28
32
31
35
19
49
40
45
41
48
46
43
42
47
44

Артикул

Название

Примечание

Количество

|$1

20G-23-31001

AXLE ASSEMBLY, FRONT

|$3

20G-23-H0P08

WHEEL HUB ASSEMBLY LHS

|$4

20G-23-H0P09

WHEEL HUB ASSEMBLY RHS

|$5

20G-23-H0P07

SEAL KIT

1

20K-23-31580

BUSHING

2

20G-23-31460

SEAL

3

20G-23-31470

RING

|$9

20G-23-31410

SHAFT

4

20G-23-H0P02

FORK

5

20J-23-11250

OUTER BODY

6

20G-23-H0P04

FORK

7

20K-23-32340

NIPPLE

8

20J-23-11240

SPIDER

9

20G-23-31510

FITTING

10

20K-22-31350

PLUG

11

20K-22-31360

PLUG

12

20K-23-31620

CIRCLIP

13

20K-23-31590

WASHER

14

20G-23-31420

BOX, JOINT

15

20G-23-31520

BOX, JOINT

16

20K-23-31570

RING

17

20K-22-31310

GASKET

18

20G-23-31450

BEARING

19

20G-23-H0P05

BOLT

|$26

20G-23-H0P13

HUB

20

20K-22-31860

STUD

21

20G-23-H0P06

HUB

22

20K-22-31440

O-RING

23

20G-23-31480

SHIM

24

20G-23-31490

SHIM

25

20G-22-31160

SHIM

26

20K-22-31260

BUSHING

27

20K-22-31250

WASHER

28

20K-22-31380

SCREW

|$36

20G-23-31890

BRAKE ASSEMBLY

29

20G-23-31910

PISTON

30

20G-23-31920

BODY, INNER

31

20K-23-31880

WASHER, THRUST

32

20K-23-31890

DISC, OUTER

33

20K-23-32210

INNER DISC

34

20K-23-31920

SCREW

35

20K-23-31930

CIRCLIP

36

20K-23-32220

PISTON GASKET

37

20K-23-32230

PISTON GASKET

38

20G-23-31950

O-RING

39

20K-14-32610

SPRING

40

20K-22-31240

CIRCLIP

41

20K-22-31230

WHEEL

|$50

20G-23-31350

PLANETARY ASSEMBLY

42

20G-23-31360

HOLDER, PLANETARY

43

20K-22-31170

GEAR, SPUR

44

20K-22-31270

PLUG

45

20K-22-31180

WASHER

46

20K-22-31190

BEARING, ROLLER

47

20K-14-32330

PLUG

48

20G-23-31370

CLIP

49

20K-22-31280

PLUG

Выбрано товаров: 57
