Запчасти Komatsu PW160-7 CENTRAL СМАЗКА (ФИДЕР ONE-ЧАСТИ-СТРЕЛА) W РАЗНОЕ

|$1

42W-09-H3150

FEEDER

1

419-09-H2850

PLASTIC TUBE, 1.07M (MARK 11)

2

419-09-H3150

COVER, 1.00M (SPIRAL)

3

419-09-H2850

PLASTIC TUBE, 2.05M (MARK 14)

4

419-09-H3150

COVER, 1.98M (SPIRAL)

5

419-09-H2850

PLASTIC TUBE, 1.07M (MARK 12)

6

419-09-H3150

COVER, 1.00M (SPIRAL)

7

42W-09-H3870

HOSE (MARK 4)

8

42W-09-H3870

HOSE (MARK 3)

9

419-09-H2850

PLASTIC TUBE, 4.20M (MARK 5)

10

42W-09-H3880

SPIRAL HOSE

11

42W-09-H2880

UNION

12

42W-09-H3840

HOSE (MARK A)

13

419-09-H2850

PLASTIC TUBE, 2.50M (MARK 1)

14

419-09-H2850

PLASTIC TUBE, 4.20M (MARK 6)

15

421-09-H3870

NIPPLE

16

42W-09-H3350

CAP

17

42W-09-H3890

PLATE

18

01010-80640

BOLT

19

42W-09-H2940

CAP

20

42W-09-H3140

FEEDER (WITH VALVES)

21

42W-09-H4650

VALVE

22

01252-61030

BOLT

23

01643-31032

WASHER

1

BOOM CYLINDER, TOP, RHS

3

ARM CYLINDER, BOTTOM

5

BOOM CYLINDER, TOP, LHS

7

BOOM FOOT PIN, RHS

8

BOOM FOOT PIN, LHS

9

BOOM CYLINDER, BOTTOM, LHS

13

SWING CIRCLE

14

BOOM CYLINDER, BOTTOM, RHS
