Запчасти Komatsu PW160-7 ЗАДН. ОТВАЛ S ПОДВЕСКА И КОЛЕСА

1

20G-910-3205

BLADE ASSEMBLY

2

20G-61-31121

CYLINDER ASSEMBLY (SEE FIG. Y1621-01A0)

3

0278-310315

ELBOW

4

07002-12034

O-RING

5

02896-61009

O-RING

6

20G-910-3282

PIN

7

20G-910-3290

PIN

8

01010-81016

BOLT

9

144-854-1890

WASHER

10

20G-910-3282

PIN

11

20G-910-3290

PIN

12

01010-81016

BOLT

13

01010-81016

BOLT

14

144-854-1890

WASHER

15

144-854-1890

WASHER

16

20G-910-3452

LINK

17

20K-910-3470

BUSHING

18

07145-00050

SEAL

19

07020-00000

FITTING

20

20G-910-3332

LINK

21

20K-910-3470

BUSHING

22

07145-00050

SEAL

23

07020-00000

FITTING

24

20G-910-3110

SPACER, 1.0MM

25

20G-910-3120

SPACER, 2.0MM

26

20G-910-3484

BRACKET ASSEMBLY

27

01010-82060

BOLT

28

01643-32060

WASHER

29

20K-910-3321

BRACKET

30

20G-47-K1690

REFLECTOR

31

01220-40516

SCREW

32

01434-10820

BOLT, WING

33

01643-30823

WASHER
