Запчасти Komatsu PW150ES-6K МОТОР ХОДА¤ ЗАДН. (ВНУТР. ЧАСТИ) (/) ( KPH) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

20E-60-K2510

TRAVEL MOTOR ASS'Y,REAR (20 KPH)

1

20E-60-K4520

HOUSING

2

20G-60-K2640

BUSHING

3

20G-60-K4910

PISTON

4

20G-60-K4920

BUSHING

5

20G-60-K2670

BOLT

6

20G-60-K4290

SPRING

7

20E-60-K4580

SPRING

8

20G-60-K4940

O-RING

9

20G-60-K4950

SCREW

10

20G-60-K4320

SCREW

11

20G-60-K2730

RING

12

20G-60-K1490

STUD

13

20G-60-K4960

PIN

14

20G-60-K1520

NUT

15

20G-60-K2750

PIN

16

20G-60-K2560

SCREW

17

20G-60-K2760

DISC

18

20E-60-K2330

POPPET

19

20G-60-K4970

COVER

20

20G-60-K4980

SCREW

21

20G-60-K4990

SCREW

22

20G-60-K5010

SCREW

23

20G-60-K5020

O-RING

24

20G-60-K4320

SCREW

25

20E-60-K4530

PLATE

26

20E-60-K4540

PISTON

27

20E-60-K4550

TRUNNION

28

20E-60-K4560

PISTON

29

20G-60-K4770

PIN

30

20G-60-K4780

GUIDE

31

20G-60-K4790

BOLT

32

20G-60-K4810

BUSHING

33

20G-60-K4820

SCREW

34

20G-60-K4220

O-RING

35

20G-60-K4830

O-RING

36

20G-60-K4840

O-RING

37

20G-60-K4850

SCREW

38

20E-60-K4570

RING

39

20G-60-K4870

PIN

40

20G-60-K4270

PIN

41

20G-60-K4880

SCREW
