Запчасти Komatsu PW150ES-6K СТРЕЛА ADJUSTMENT ЦИЛИНДР (ВНУТР. ЧАСТИ) (ДЛЯ -ЧАСТИS СТРЕЛА) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

20E-63-K1900

CYLINDER ASS'Y,ADJUST

|1

20G-63-03180

CYLINDER ASS'Y,ADJUST

1

20E-63-K1910

CYLINDER

|1

20G-63-82140

CYLINDER

2

707-76-90130

BUSHING

|2

707-76-90440

BUSHING

3

205-70-62180

SEAL,DUST

|3

07145-00090

SEAL,DUST

4

07020-00000

FITTING,GREASE

5

20E-63-K1920

ROD

|5

20G-63-82120

ROD

6

207-63-76170

BUSHING

7

205-70-62180

SEAL,DUST

|7

07145-00090

SEAL,DUST

8

07020-00000

FITTING,GREASE

9

20G-63-K1590

HEAD

|9

707-27-16940

HEAD

10

176-63-56170

SEAL,DUST

11

07179-13114

RING,SNAP

12

707-52-90750

BUSHING

|12

707-52-90780

BUSHING

13

707-51-10030

PACKING,ROD

14

707-51-10630

RING,BUFFER

15

07001-05155

RING,BACK-UP

|15

707-35-91640

RING,BACK-UP

16

07000-15155

O-RING

|16

07000-15150

O-RING

17

01010-82085

BOLT

18

707-88-75310

WASHER

19

707-36-16480

PISTON

20

01310-01216

SCREW

21

707-44-16180

RING,PISTON

22

707-39-16820

RING,WEAR

23

707-44-16910

RING

24

07001-05100

RING,BACK-UP

|24

07001-05090

RING,BACK-UP

25

07000-15100

O-RING

|25

07000-15090

O-RING
