Запчасти Komatsu PW150ES-6K КАБИНА (/7) (ПЕРЕДН. ОКНА) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

20E-54-K6510

OPERATOR'S CAB ASS'Y

|1

20G-54-K5000

OPERATOR'S CAB ASS'Y

|1

20Y-54-43102

FRONT WINDOW ASS'Y

1

20Y-54-43112

WINDOW

2

20Y-54-38122

GLASS

3

20Y-54-38132

WEATHER STRIP

4

20Y-54-38142

SEAL

5

20Y-54-38152

SEAL

6

20Y-54-43130

LATCH ASS'Y,L.H.

|6

20Y-54-43140

LATCH ASS'Y,R.H.

7

01435-30816

BOLT

8

20Y-54-37810

STOPPER,L.H.

9

01023-70416

SCREW

10

20Y-54-37820

STOPPER,R.H.

11

01023-70416

SCREW

12

20Y-54-14290

STOPPER

13

01580-11008

NUT

14

20Y-54-14590

HANDLE

15

01023-40616

SCREW

16

20Y-54-14310

STRIKER

17

20Y-54-14280

SCREW

18

20Y-54-36834

BLOCK,L.H.

|18

20Y-54-36844

BLOCK,R.H.

19

01252-50635

BOLT

20

01641-50608

WASHER

21

20Y-54-39152

ROLLER

22

205-54-63310

LOCK ASS'Y

23

01435-30820

BOLT

24

20Y-54-39363

BRACKET

25

01435-30820

BOLT

26

154-61-16570

WASHER

27

08074-40000

SWITCH

28

01583-11811

NUT

29

20Y-54-39590

WIRING HARNESS

30

20Y-54-36150

GROMMET

31

08051-00801

CLIP

32

20Y-54-14721

LOCK

33

01435-30820

BOLT

|34

20Y-54-43201

LOWER WINDOW ASS'Y

34

20Y-54-43210

LATCH ASS'Y,L.H.

|34

20Y-54-43220

LATCH ASS'Y,R.H.

35

20Y-54-36142

PLATE

36

08037-01610

GROMMET

37

01225-70612

SCREW

38

20Y-54-36211

COVER

39

20Y-54-36113

GLASS

40

20Y-54-36171

SEAT

41

20Y-54-36230

SHIM¤ 2.0MM

42

01370-00620

SCREW

43

20Y-54-36182

STOPPER

44

01435-30820

BOLT
