Запчасти Komatsu PW150-1 ЗАДН. МОСТ (CALIPER)(№-) МОСТ¤ КОЛЕСА И СИСТЕМАУПРАВЛЕНИЯ ПОВОРОТОМ

Схема запчастей Komatsu PW150-1 - ЗАДН. МОСТ (CALIPER)(№-) МОСТ¤ КОЛЕСА И СИСТЕМАУПРАВЛЕНИЯ ПОВОРОТОМ
1
1
2
3
3
4
4
5
6
6
6
6
7
7
7
7
8
8
8
8
9
9
9
9
10
10
10A
11
12
12
13
13
14
14
15
15
16
16
16
16
17
17
17
17
18
18
18
18
19
20
21
22
23

Артикул

Название

Примечание

Количество

|1

20G-22-29003

REAR AXLE ASS'Y

|1

20G-22-29100

REAR AXLE ASS'Y,(FOR NON ASBESTOS)

|1

20G-32-21473

BRAKE ASS'Y,REAR AXLE R.H.

|1

20G-32-21701

BRAKE ASS'Y,REAR AXLE R.H. (NON ASBESTOS)

|1

20G-32-21700

BRAKE ASS'Y,REAR AXLE R.H. (NON ASBESTOS)

|1

20G-32-21107

BRAKE ASS'Y,REAR AXLE L.H.

|1

20G-32-21601

BRAKE ASS'Y,REAR AXLE L.H. (NON ASBESTOS)

|1

20G-32-21600

BRAKE ASS'Y,REAR AXLE L.H. (NON ASBESTOS)

|1

20G-32-21112

CALIPER ASS'Y

1

CALIPER,HALF

2

CALIPER,HALF

3

SEAL,CALIPER (K6)

4

BOLT,BRIDGE

|4

BOLT,BRIDGE

5

BOLT,BRIDGE

|5

BOLT,BRIDGE

6

SEAL,PISTON (K6)

7

20G-32-21230

SEAL,DUST (K6)

8

20G-32-21241

INSERT,PISTON

9

20G-32-21250

RING,RETAINING (K6)

10

PAD (K7)

|10

PAD,(FOR NON ASBESTOS) (K7)

10A

SPRING (K7)

11

20G-32-21333

PIN,SUPPORT

|11

20G-32-21332

PIN,SUPPORT

12

20G-32-21460

WASHER

|13

01596-00606

NUT

13

426-09-11130

NUT

14

20G-32-21130

BREATHER,BLEED

15

20G-32-21140

CAP

16

20G-32-21211

PISTON

17

20G-32-21280

BALL

18

20G-32-21290

O-RING

19

20G-32-21150

PLUG

20

20G-32-21550

PLUG

21

20G-32-21560

BLEEDER

22

20G-32-21140

CAP

23

20G-32-21160

O-RING

K6

20G-32-21221

CALIPER SEAL KIT

|K6

20G-32-21250

RING,RETAINING

|K6

SEAL,PISTON

|K6

20G-32-21230

SEAL,DUST

|K6

OIL,PRESERVATIVE

|K6

GREASE,RUBBER

K7

20G-32-21312

CALIPER PAD KIT

|K7

20G-32-21611

PAD KIT,(FOR NON ASBESTOS)

|K7

20G-32-21610

PAD KIT,(FOR NON ASBESTOS)

|K7

PAD

|K7

20G-32-21641

PAD,(FOR NON ASBESTOS)

|K7

PAD,(FOR NON ASBESTOS)

Выбрано товаров: 50
