Запчасти Komatsu PW150-1 ПЕРЕДНИЙ МОСТ (КОНЕЧНАЯ ПЕРЕДАЧА) МОСТ¤ КОЛЕСА И СИСТЕМАУПРАВЛЕНИЯ ПОВОРОТОМ

|1

20G-22-20004

FRONT AXLE ASS'Y

|1

20G-22-20003

FRONT AXLE ASS'Y

|1

20G-22-20002

FRONT AXLE ASS'Y

|1

20G-22-20101

FRONT AXLE ASS'Y,(FOR NON ASBESTOS)

|1

20G-22-20100

FRONT AXLE ASS'Y,(FOR NON ASBESTOS)

1

20G-32-21910

DISC

2

20G-32-21950

BOLT,12POINT

3

20G-22-22710

HUB

|4

20G-22-12320

BEARING

4

20G-22-12340

CUP,BEARING

5

20G-22-12330

CONE,BEARING

6

20G-22-12750

SEAL,OIL

7

20G-22-22791

RING

|7

20G-22-22790

RING

8

20G-22-22140

BOLT

9

20G-22-22130

PLATE,LOCK

|10

20G-22-22350

BEARING,BEARING

|10

20G-22-22370

CUP

11

20G-22-22360

CONE,BEARING

12

20G-22-22310

HUB,RING GEAR

13

20G-22-22110

GEAR,RING

14

20G-22-12440

SHIM¤ 0.10MM

|14

20G-22-12450

SHIM¤ 0.15MM

|14

20G-22-12460

SHIM¤ 0.20MM

|14

20G-22-12470

SHIM¤ 0.50MM

15

20G-22-12431

RETAINER

|15

20G-22-12430

RETAINER

16

01252-31045

BOLT

17

20G-22-22420

GEAR,SUN

18

20G-22-12490

RING

19

04064-04018

RING,SNAP

20

20G-22-22612

CARRIER

|20

20G-22-22611

CARRIER

21

130-09-14330

BEARING

|21

20G-22-22220

BEARING

22

20G-22-22210

GEAR,PLANETARY

23

20G-22-22270

WASHER

24

20G-22-12260

WASHER

25

20G-22-22651

SHAFT

26

07000-13045

O-RING

27

04025-00820

PIN

|27

419-22-12570

PIN

28

20G-22-12630

BUTTON,THRUST

29

20G-22-12680

O-RING

30

07000-02012

O-RING

31

01010-31235

BOLT

32

20G-22-22720

BOLT

33

20G-22-12870

NUT

34

20G-22-12880

COLLAR

35

20G-22-12860

WASHER,SPRING

36

176-76-67150

PLUG

|36

07040-12414

PLUG

37

07002-02434

O-RING

38

07040-11007

PLUG

39

07002-01023

O-RING

40

20G-32-21930

BOLT,12POINT¤ FRONT AXLE

|40

20G-32-21930

BOLT,12POINT¤ REAR AXLE
