Запчасти Komatsu PW150-1 ЗАДН. МОСТ (CALIPER)(№-) МОСТ¤ КОЛЕСА И СИСТЕМАУПРАВЛЕНИЯ ПОВОРОТОМ

|$0

20G-22-29003

REAR AXLE ASS'Y

|$2

20G-22-29100

REAR AXLE ASS'Y,(FOR NON ASBESTOS)

|$4

20G-32-21473

BRAKE ASS'Y,REAR AXLE R.H.

|$5

20G-32-21701

BRAKE ASS'Y,REAR AXLE R.H. (NON ASBESTOS)

|$6

20G-32-21700

BRAKE ASS'Y,REAR AXLE R.H. (NON ASBESTOS)

|$7

20G-32-21107

BRAKE ASS'Y,REAR AXLE L.H.

|$8

20G-32-21601

BRAKE ASS'Y,REAR AXLE L.H. (NON ASBESTOS)

|$9

20G-32-21600

BRAKE ASS'Y,REAR AXLE L.H. (NON ASBESTOS)

|$10

20G-32-21112

CALIPER ASS'Y

1

CALIPER,HALF

2

CALIPER,HALF

3

SEAL

4

BOLT,BRIDGE

4

BOLT,BRIDGE

5

BOLT,BRIDGE

5

BOLT,BRIDGE

6

SEAL,PISTON (K6)

7

20G-32-21230

SEAL,DUST (K6)

8

20G-32-21241

INSERT,PISTON

9

20G-32-21250

RING,RETAINING (K6)

10

PAD (K7)

10

PAD,(FOR NON ASBESTOS) (K7)

10A

SPRING (K7)

11

20G-32-21333

PIN,SUPPORT

11

20G-32-21332

PIN,SUPPORT

12

20G-32-21460

WASHER

|$28

01596-00606

NUT

13

426-09-11130

NUT

14

20G-32-21130

BREATHER,BLEED

15

20G-32-21140

CAP

16

20G-32-21211

PISTON

17

20G-32-21280

BALL

18

20G-32-21290

O-RING

19

20G-32-21150

PLUG

20

20G-32-21550

PLUG

21

20G-32-21560

BLEEDER

22

20G-32-21140

CAP

23

20G-32-21160

O-RING

K6

20G-32-21221

CALIPER SEAL KIT

K6

20G-32-21250

RING,RETAINING

K6

SEAL,PISTON

K6

20G-32-21230

SEAL,DUST

K6

OIL,PRESERVATIVE

K6

GREASE,RUBBER

K7

20G-32-21312

CALIPER PAD KIT

K7

20G-32-21611

PAD KIT,(FOR NON ASBESTOS)

K7

20G-32-21610

PAD KIT,(FOR NON ASBESTOS)

K7

PAD

K7

20G-32-21641

PAD,(FOR NON ASBESTOS)

K7

PAD,(FOR NON ASBESTOS)
