Запчасти Komatsu PW150-1 ПЕРЕДНИЙ МОСТ (КУЛАК И ПОПЕРЕЧНАЯ РУЛЕВ. ТЯГА) МОСТ¤ КОЛЕСА И СИСТЕМАУПРАВЛЕНИЯ ПОВОРОТОМ

|$0

20G-22-20004

FRONT AXLE ASS'Y

|$2

20G-22-20003

FRONT AXLE ASS'Y

|$6

20G-22-20002

FRONT AXLE ASS'Y

|$8

20G-22-20101

FRONT AXLE ASS'Y,(FOR NON ASBESTOS)

|$10

20G-22-20100

FRONT AXLE ASS'Y,(FOR NON ASBESTOS)

1

20G-22-23512

KNUCKLE,R.H.

1

20G-22-23511

KNUCKLE,R.H.

2

20K-22-13522

KNUCKLE,L.H.

2

20K-22-13521

KNUCKLE,L.H.

2

20G-22-23520

KNUCKLE,L.H.

3

22X-22-13530

BUSHING

4

20G-22-23811

PIN,KING

5

20G-22-13850

SHIM, 0.10MM

5

20G-22-13860

SHIM, 0.15MM

5

20G-22-13870

SHIM, 0.20MM

5

20G-22-13880

SHIM, 0.50MM

6

01010-62050

BOLT

7

20G-22-23550

SPINDLE

8

20G-22-12570

BUSHING

9

20G-22-12590

SEAL,OIL

10

20G-22-22730

RETAINER

11

07000-02100

O-RING

12

01010-61840

BOLT

13

20G-22-22780

SCAVENGER

14

07270-00505

TUBE

|$35

20G-22-22512

U-JOINT ASS'Y

|$36

20G-22-22511

JOINT ASS'Y

|$37

20G-22-22510

JOINT ASS'Y

15

20G-22-22532

SHAFT,YOKE

15

20G-22-12531

SHAFT,YOKE

15

20G-22-12530

SHAFT,YOKE

16

20G-22-22522

SHAFT,YOKE

16

20G-22-22521

SHAFT,YOKE

16

20G-22-12520

SHAFT,YOKE

|$44

20G-22-22691

SPIDER ASS'Y

|$45

20G-22-22690

SPIDER ASS'Y

17

SPIDER

|$47

20G-22-22570

BEARING ASS'Y

18

GASKET

19

BEARING,NEEDLE

20

CASE

21

20G-22-12551

RING,SNAP

21

20G-22-12550

RING,SNAP

22

20G-22-22561

FITTING,GREASE

22

20G-22-22560

FITTING,GREASE

23

22X-22-13320

CLEVIS

24

20G-22-13311

ROD,TIE

25

01583-03923

NUT

26

01010-31265

BOLT

27

01580-01210

NUT

28

01602-01236

WASHER,SPRING

29

22X-22-13330

PIN

30

07020-00000

FITTING,GREASE

31

01596-02016

NUT

31

01598-02021

NUT

32

01643-32060

WASHER

33

20G-22-23822

STEERING ARM ASS'Y

33

20G-22-23821

STEERING ARM ASS'Y

34

04022-25050

PIN,DOWEL

34

04022-25045

PIN,DOWEL

35

07143-10404

BUSHING

36

07145-00040

SEAL,DUST

37

07020-00000

FITTING,GREASE

39

01010-62055

BOLT

39

01010-62050

BOLT
