Запчасти Komatsu PW150-1 МАРКИРОВКА (ПОРТУГАЛ.) (/) (ДЛЯ ABE СПЕЦ-Я.) СПЕЦ. APPLICATION ЧАСТИ¤ МАРКИРОВКА¤ ИНСТРУМЕНТ И РЕМКОМПЛЕКТЫ

1

09669-00003

PLATE, CAUTION

2

09669-00002

PLATE, CAUTION

3

09653-02000

PLATE, SAFETY,HYDRAULIC TANK CAP

4

20T-98-22330

PLATE, SAFETY,ENGINE COVER

5

09152-02000

PLATE, SAFETY,AIR RESERVOIR

6

20G-54-11960

SEAT,NON SKID

7

154-54-23260

SEAT,NON SKID

8

125-54-33451

SHEET,NON SKID

9

20G-00-11890

MARK,ZEBRA

10

20T-98-22240

PLATE, SAFETY,OFFLIMIT WITH SWING AREA

11

09690-50500

PLATE, MARK,KOMATSU

12

20G-00-11111

PLATE,PW150

13

142-54-16170

STRIPE,LINE

14

205-00-63770

PLATE,RUBBER, GUARD

15

203-00-41131

PLATE, MARK,KOMATSU

16

20G-00-11121

PLATE,PW150

17

20G-00-11261

PLATE,FUEL LEVEL GAUGE

18

09690-41250

PLATE, MARK,KOMATSU

19

20G-00-11950

MARK,ZEBRA

20

09685-00003

PLATE, OPERATING,BOOM LOCK VALVE

21

362-98-11661

PLATE, NAME,PW150

21

362-98-11660

PLATE,PW150

22

01220-60408

SCREW

23

01601-20410

WASHER,SPRING

24

09685-00003

PLATE, OPERATING,BOOM CIRCUIT
