Запчасти Komatsu PW148-8 ЦИЛИНДР РУКОЯТИ(С КЛАПАН БЕЗОПАСНОСТИ) (ВНУТР. ЧАСТИ) (№H-UP) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-G1-X1800

CYLINDER GROUP

|$58

707-E1-X1800

CYLINDER ASSEMBLY

1

07372-21050

BOLT

2

01643-51032

WASHER

3

01643-51032

WASHER

4

07372-21060

BOLT

5

702-21-08870

PILOT VALVE

6

07000-13030

O-RING (KIT)

7

07372-21035

BOLT

8

01643-51032

WASHER

9

707-86-48320

UNION

10

07000-13030

O-RING (KIT)

11

02782-10522

ELBOW

12

02896-11015

O-RING (KIT)

13

07002-12434

O-RING (KIT)

14

01643-51032

WASHER

15

07372-21035

BOLT

16

707-88-28740

CLAMP

17

707-83-21271

CLAMP

18

707-87-14070

PLUG

19

01643-51645

WASHER

20

01010-81670

BOLT

21

707-76-70240

BUSHING

22

07145-00070

SEAL (KIT)

23

07179-13089

CIRCLIP

24

707-56-75740

SEAL, DUST (KIT)

25

707-27-11750

HEAD

26

707-51-75030

SEAL (KIT)

27

707-51-75650

RING (KIT)

28

07000-15105

O-RING (KIT)

29

707-35-91150

RING, BACK-UP (KIT)

30

707-52-90501

BUSHING

31

707-75-75110

RING

32

707-71-32570

COLLAR

33

07000-15105

O-RING (KIT)

34

707-35-91150

RING, BACK-UP (KIT)

35

707-13-11780

CYLINDER

36

707-58-75670

ROD

37

707-71-70810

PLUNGER

38

707-36-11851

PISTON

39

707-44-11920

RING

40

707-35-90360

RING (KIT)

41

07000-15070

O-RING (KIT)

42

707-39-11530

RING (KIT)

43

707-44-11250

RING (KIT)

44

707-71-91270

CAP

45

04260-00635

BALL

46

707-71-80230

PLUNGER

47

707-83-13010

VALVE

48

07750-01628

SPRING

49

01310-01216

SCREW

50

07002-12034

O-RING (KIT)

KIT

707-99-45190

SERVICE KIT
