Запчасти Komatsu PW148-8 ОСНОВН. НАСОС (/7) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-1L-00690

MAIN PUMP

|$3

708-1L-01690

PUMP SUB ASSEMBLY

1

708-2L-34120

SLIDER

|$5

708-1L-04850

VALVE ASSEMBLY

|$6

708-2L-06660

PISTON ASSEMBLY

2

PISTON

3

SCREW

4

708-2L-35680

SEAL

5

708-2L-35621

PLUG

6

708-2L-35760

BALL

7

708-2L-35770

PLUG

8

708-2L-35690

SEAL

9

708-2L-35170

PIN

10

708-2L-35860

SPOOL

11

708-2L-35630

RETAINER

12

708-2L-35641

SEAT

13

708-2L-35730

SPRING

14

708-1L34160

SPRING

15

708-2L-35650

SEAT

16

708-2L-35730

SPRING

17

708-2L-34330

SCREW

18

07000-B3034

O-RING

19

708-2L-35210

RING

20

708-2L-35710

SEAL

21

708-2L-35270

PIN

22

07000-B2011

O-RING

23

07000-B3045

O-RING

24

708-2L-35750

RING

25

708-2L-34230

COVER

26

01580-10806

NUT

27

708-2L-35290

NUT

28

708-2L-35670

RING

29

01252-61440

BOLT
