/ / / / / / ONE-ЧАСТИ СТРЕЛА - CENTRAL СМАЗКА (АВТОМАТИЧ.)
Запчасти Komatsu PW148-8 ONE-ЧАСТИ СТРЕЛА - CENTRAL СМАЗКА (АВТОМАТИЧ.) T РАБОЧЕЕ ОБОРУДОВАНИЕ
14
A
15
A
13
17
16
18
26
21
9
10
28
19
26
25
5
25
6
26
27
21
2
24
12
1
23
7
14
4
15
11
3
13
8
17
18
16
22
26
20
26
26
26
22
22
1
01010-81016
BOLT
2
01643-31032
WASHER
3
01010-81035
BOLT
4
01643-31032
WASHER
5
01010-81065
BOLT
6
01643-31032
WASHER
7
04434-51210
CLIP
8
04435-51210
CLIP
9
08034-20536
BAND
10
20E-S95-H470
PLATE
11
20E-S95-H520
MAIN FEEDER (1PB)
12
20E-S95-H740
BOOM FEEDER (1PB)
13
42W-09-H0P03
HOSE, 5M
|$16
42W-09-H0P04
HOSE, 10M
|$17
42W-09-H0P05
HOSE, 25M
14
419-S95-HP13
TUBE
15
419-S95-HP14
BUSHING
16
42W-09-H0P03
HOSE, 5M
|$21
42W-09-H0P04
HOSE, 10M
|$22
42W-09-H0P05
HOSE, 25M
17
419-S95-HP13
TUBE
18
419-S95-HP14
BUSHING
19
419-09-H3020
COVER
20
419-09-H2780
UNION
21
419-09-H2950
UNION
22
419-09-H2970
ELBOW
23
419-09-H2980
ELBOW
24
423-00-H2070
UNION
25
42W-09-H2880
UNION
26
42W-09-H2940
CAP
27
42W-09-H3320
SEAL WASHER
28
42W-09-H3540
UNION
