Запчасти Komatsu PW148-8 ОХЛАДИТЕЛЬ ASSEMBLY C СИСТЕМА ОХЛАЖДЕНИЯ

|$1

20E-03-41101

COOLER ASSEMBLY

1

203-03-41410

HOSE

2

205-03-62660

PLUG

3

206-03-43340

CLIP

4

208-03-71161

FUEL COOLER

5

01010-80820

BOLT

6

01010-81020

BOLT

7

01010-80816

BOLT

8

01010-80835

BOLT

9

01010-81020

BOLT

10

01010-81025

BOLT

11

01010-81030

BOLT

12

01010-81225

BOLT

13

01010-81245

BOLT

14

01434-10616

BOLT WING

15

01597-01009

NUT

16

01640-21016

WASHER

17

01643-30623

WASHER

18

01643-30823

WASHER

19

01643-31032

WASHER

20

02782-10315

ELBOW

21

6738-61-4952

COLLAR

22

07000-13045

O-RING

23

07002-12034

O-RING

24

07283-34354

CLIP

25

07283-54353

SEAT

26

20E-03-31190

SHEET

27

20E-03-31311

NET

28

20E-03-31321

NET

29

20E-03-31371

OIL COOLER INLET PIPE

30

20E-03-31381

OIL COOLER OUTLET PIPE

31

20E-03-31390

BRACKET

32

20E-03-31411

BRACKET

33

20E-03-31421

AFTER COOLER

34

20E-03-41110

RADIATOR ASSEMBLY

35

20E-03-41130

FRAME, LHS

36

20E-03-41140

FRAME, TOP

37

20E-03-41150

PLATE

38

20E-03-41160

PLATE

39

20E-03-41180

SHEET

40

20E-03-41190

OIL COOLER

41

20E-03-41280

COVER

42

20E-03-41290

PLATE

43

20E-03-41310

PLATE

44

20E-03-41340

SHEET

45

20E-03-41350

SHEET

46

20E-03-41390

FRAME, BASE

47

20E-03-41410

FRAME, RHS

48

20E-03-41620

BRACKET

49

20G-03-31420

PLATE

50

20J-03-11310

SHEET

51

20J-03-11560

HOSE

52

20Y-03-11330

CLIP

53

20Y-03-22110

CAP

54

20Y-03-41580

CUSHION

55

20Y-810-1221

CONDENSER ASSEMBLY

56

20Y-810-1240

BUSH

57

22U-03-22860

CUSHION

58

01643-30823

WASHER

59

01643-31032

WASHER

60

01643-31232

WASHER
