Запчасти Komatsu PW148-8 OPERATORґS КАБИНА IN ЧАСТИ - ЗАДН. КРЫШКА И 12В КОНВЕРТЕР K OPERATORґS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$1

20Y-53-12371

REAR COVER ASSEMBLY

1

COVER

2

208-53-12290

HOOK

3

01640-20408

WASHER

4

01640-20410

WASHER

5

01580-10403

NUT

|$7

20Y-53-13631

COVER ASSEMBLY

6

COVER

7

22U-43-22340

PULLER

8

08041-03000

FUSE, 30A

9

08041-02000

FUSE, 20A

10

08041-01000

FUSE, 10A

11

01435-40616

BOLT

12

20Y-53-12310

COLLAR

13

208-979-7560

GRILLE

|$16

20Y-53-12351

COVER

14

01370-10308

SCREW

15

01370-20308

SCREW

16

09452-14503

CATCHER

17

208-53-12320

PIN

18

208-53-12330

RING

19

208-53-12410

PLATE

20

COVER

21

20Y-53-12391

COVER

22

01435-40616

BOLT

23

20Y-53-12310

COLLAR

24

20Y-53-12931

COVER

25

01435-40620

BOLT

26

20Y-53-12310

COLLAR

27

23D-950-4450

BUTTON

28

20Y-53-12860

SPACER

29

22U-06-22251

CONVERTER

30

01435-00610

BOLT

31

198-Z11-2640

SOCKET

32

08034-20414

BAND

33

20Y-53-18221

BRACKET

34

01435-00612

BOLT
