Запчасти Komatsu PW140-7 ГИДРАВЛ МАСЛ. БАК H ГИДРАВЛИКА

|$43

20E-60-32113

HYDRAULIC TANK ASSEMBLY

1

01010-81230

BOLT

2

01643-31232

WASHER

3

01252-70516

BOLT

4

01601-20513

WASHER

5

07002-12434

O-RING

6

07044-12412

PLUG

7

07270-61512

TUBE

8

07285-00155

CLIP

9

17A-60-11310

CAP ASSEMBLY

|$42

20Y-60-21470

ELEMENT

10

TANK

11

20Y-60-21240

SPRING

12

20Y-60-21340

GASKET

13

20Y-60-21460

FILLER NECK

14

207-60-71181

ELEMENT

15

20Y-60-31131

VALVE ASSEMBLY

16

20Y-60-31140

STRAINER

17

20Y-60-31171

STRAINER ASSEMBLY

18

20Y-60-K1480

GAUGE

19

20E-60-31310

COVER

20

22U-60-21232

COVER

21

07000-15160

O-RING

22

07000-15195

O-RING

23

02782-10315

ELBOW

24

02896-11009

O-RING

25

07002-12034

O-RING

26

02782-10316

ELBOW

27

02782-10423

ELBOW

28

02896-11012

O-RING

29

02782-10628

ELBOW

30

56B-43-17370

NIPPLE

31

02896-11018

O-RING

32

8287-62-1510

ADAPTER

33

11Y-62-12170

ELBOW

34

02896-11008

O-RING

35

01010-81635

BOLT

36

01643-31645

WASHER

37

195-03-11570

SHIM

38

20E-60-31320

GASKET

39

20E-60-42150

FILTER ELEMENT

|$45

20E-60-42160

TANK CAP

40

20E-60-H0P04

BREATHER

41

20E-60-H0P00

PIN

42

BOLT

43

O-RING

44

FLANGE

45

20E-60-H0P07

SEAL
