Запчасти Komatsu PW140-7 ЦИЛИНДР ОПОРЫ (ВНУТР. ЧАСТИ) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

20G-61-31130

CYLINDER ASSEMBLY

1

20E-62-K9570

CYLINDER

2

20E-62-K9580

PISTON ROD

3

20E-63-K5280

PISTON

4

20E-63-K5290

GUIDE

5

20E-62-K9590

CONTROL SPOOL

6

20E-62-K6190

VALVE SEAT

7

20E-63-K9560

VALVE POPPET (CPLT.)

8

20E-62-K6440

VALVE POPPET

9

20E-62-K6450

SCREW PLUG

10

20E-63-K5380

BEARING

11

20E-63-K5390

CIRCLIP

12

20E-63-K5410

GREASE NIPPLE

13

20E-63-K5110

WIPER (KIT)

14

20E-63-K5120

RING (KIT)

15

20E-63-K5130

ROD WEAR RING (KIT)

16

20E-63-K5140

O-RING (KIT)

17

20E-63-K5150

BACK-UP RING (KIT)

18

20E-63-K5160

O-RING (KIT)

19

20E-63-K5170

RING (KIT)

20

20E-63-K5180

O-RING (KIT)

21

20E-63-K5190

BACK-UP RING (KIT)

22

20E-63-K5210

PISTON WEAR RING (KIT)

23

20E-63-K5220

O-RING (KIT)

24

20E-63-K5230

BACK UP RING (KIT)

25

20E-62-K6630

O-RING (KIT)

26

20E-61-K2450

BACK-UP RING (KIT)

27

20E-62-K6640

O-RING (KIT)

28

20E-62-K6670

PRESSURE SPRING

29

20E-63-K5360

GROOVE NUT

30

20E-63-K5370

SCREW

KIT

20E-63-K5860

SEAL KIT
