Запчасти Komatsu PW140-7 СТРЕЛА ADJUST ЦИЛИНДР (ВНУТР. ЧАСТИ) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XP940

CYLINDER

1

707-86-48280

TUBE

2

07372-21045

BOLT

3

07372-21060

BOLT

4

01643-51032

WASHER

5

07000-13030

O-RING (KIT)

6

01010-81025

BOLT

7

01643-31032

WASHER

8

07282-12288

CLAMP

9

02896-11015

O-RING (KIT)

10

707-88-28730

BRACKET

11

707-88-21370

CLAMP

12

07372-21035

BOLT

13

01643-51032

WASHER

|$16

707-01-0K940

CYLINDER ASSEMBLY

14

07179-13089

CIRCLIP

15

144-63-94170

STRIPPER (KIT)

16

707-27-14990

HEAD

17

707-51-75030

SEAL (KIT)

18

707-51-75650

RING (KIT)

19

707-35-91420

RING (KIT)

20

07000-15130

O-RING (KIT)

21

707-52-90500

BUSHING

22

707-75-75110

RING

23

707-58-75820

ROD

24

707-13-14930

CYLINDER

25

707-36-14770

PISTON

26

707-35-90930

RING (KIT)

27

07000-15075

O-RING (KIT)

28

707-44-14150

RING (KIT)

29

707-39-14110

RING (KIT)

30

707-44-14910

RING

31

01310-01216

SCREW

32

07145-00080

SEAL (KIT)

33

707-76-80010

BUSHING

34

01010-81875

BOLT

35

707-41-11840

WASHER

KIT

707-99-53300

SERVICE KIT
