Запчасти Komatsu PW140-7 ЦИЛИНДР ОТВАЛА (ВНУТР. ЧАСТИ) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

20E-61-31110

CYLINDER ASSEMBLY

1

20E-61-31340

CYLINDER

2

20E-61-31330

PISTON ROD

3

20E-61-31320

PISTON

4

20E-61-31310

GUIDE

5

20K-61-31520

CONTROL SPOOL

6

20G-61-K2240

THROTTLE BOLT

7

20E-61-31290

SEAT

8

20K-61-31510

SEAT

9

20K-61-31480

POPPET

10

20K-61-31450

PLUG

11

207-63-KA680

PLUG

12

20E-61-31280

WIPER (KIT)

13

20E-61-31270

U-RING (KIT)

14

20E-61-31260

ROD WEAR-RING (KIT)

15

20E-61-31250

O-RING (KIT)

16

20E-61-31240

RING (KIT)

17

20E-61-31230

O-RING (KIT)

18

20E-61-31220

TURCON-GLYD-RING (KIT)

19

20E-61-31210

O-RING (KIT)

20

20E-61-31190

RING (KIT)

21

207-63-KA570

PISTON WEAR-RING (KIT)

22

20E-61-31180

O-RING (KIT)

23

20E-61-31170

RING (KIT)

24

20K-61-31310

O-RING (KIT)

25

20K-61-31290

RING (KIT)

26

20K-61-31280

O-RING (KIT)

27

20K-61-31270

SPRING

28

20E-61-31160

GROOVE NUT

29

20E-61-31150

GRUB SCREW

30

20E-61-31140

BEARING

31

20E-61-31130

CIRCLIP

32

20K-61-31220

NIPPLE

KIT

20E-61-H0P01

SEAL KIT
