Запчасти Komatsu PW140-7 МЕХАНИЗМ ПОВОРОТА Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

1

706-73-01181

SWING MOTOR (SEE FIG. Y1610-02A0)

2

203-26-61350

FILLER, GAUGE

3

201-26-62360

GAUGE, OIL

|$5

203-26-00140

SWING MACHINERY ASSEMBLY

4

01011-81230

BOLT

5

01643-31232

WASHER

6

07049-01215

PLUG

7

203-26-61360

O-RING

8

201-26-62190

RING

9

203-26-61110

GEAR

10

20S-26-71190

RING, SNAP

11

20S-26-71160

WASHER

12

203-26-61160

GEAR

13

201-26-62270

BEARING

14

201-26-62240

SHAFT

15

203-26-61150

GEAR

16

04064-05520

RING, SNAP

17

203-26-61120

CARRIER

18

20S-26-71250

PIN

19

203-26-61280

SPACER

20

203-26-61170

GEAR

21

203-26-61130

CARRIER

22

203-26-61250

SHAFT

23

20S-26-71250

PIN

24

09233-12920

WASHER, THRUST

25

203-26-61180

GEAR

26

203-26-61270

BEARING

27

203-26-61310

COLLAR

28

203-26-61391

SPACER

29

201-26-62330

BEARING

30

203-26-61360

O-RING

31

CASE

32

203-26-61370

NIPPLE

33

07323-30400

ELBOW

34

07042-30415

PLUG

35

07049-02025

PLUG

36

07012-00145

SEAL, OIL

37

203-26-61320

BEARING

38

203-26-61340

COLLAR

39

07000-02080

O-RING

40

203-26-61220

SHAFT
