Запчасти Komatsu PW140-7 CENTRAL СМАЗКА (ФИДЕР .M РУКОЯТЬ) W РАЗНОЕ

Схема запчастей Komatsu PW140-7 - CENTRAL СМАЗКА (ФИДЕР .M РУКОЯТЬ) W РАЗНОЕ
9
12
b
b
a
a
1
4
8
13
2
16
11
5
10
3
14
15
11
13
15
14
6
18
17
7
4
3
7
2
5

Артикул

Название

Примечание

Количество

|$2

42W-09-H4980

PROGRESSIVE FEEDER

1

42W-09-H5000

HOSE (MARK 19)

|$4

419-09-H3150

COVER, 1.20M (SPIRAL)

2

42W-09-H5020

HOSE (MARK 18)

|$6

419-09-H3150

COVER, 0.64M (SPIRAL)

3

42W-09-H3730

HOSE (MARK 17)

|$8

419-09-H3150

COVER, 0.69M (SPIRAL)

4

42W-09-H4520

HOSE (MARK 15)

|$10

419-09-H3150

COVER (SPIRAL)

5

42W-09-H4530

HOSE (MARK 18)

|$12

419-09-H3150

COVER (SPIRAL)

6

42W-09-H5010

HOSE (MARK 15)

|$14

419-09-H3150

COVER, 0.73M (SPIRAL)

7

42W-09-H4990

HOSE (MARK 16)

|$32

419-09-H3150

COVER, 0.68M (SPIRAL)

8

42W-09-H3760

ELBOW

9

42W-09-H3750

HOSE

|$18

42W-09-H3360

COVER (SPIRAL)

10

42W-09-H3700

FEEDER (WITH VALVES)

11

42W-09-H4650

VALVE

12

01010-80640

BOLT

13

419-09-H2860

CAP

14

421-09-H3870

NIPPLE

15

42W-09-H3350

CAP

16

42W-09-H3770

PLATE

17

01010-81030

BOLT

18

01643-31032

WASHER

Выбрано товаров: 27
