Запчасти Komatsu PW140-7 CENTRAL СМАЗКА (.M РУКОЯТЬ) W РАЗНОЕ

Схема запчастей Komatsu PW140-7 - CENTRAL СМАЗКА (.M РУКОЯТЬ) W РАЗНОЕ
8
9
13
7
6
5
4
3
9
13
3
10
11
1
2
12
1
2
14
3
17
8
15
9
18
19
21
16
9
20
9
36
22
37
20
9
21
23
24
17
35
34
33
32
25
26
27
29
9
28
31
30

Артикул

Название

Примечание

Количество

1

20E-S95-H270

LUBRICATION PIPE

2

20E-S95-H280

LUBRICATION PIPE

3

423-00-H1690

STRAIGHT COUPLING

4

20E-S95-H131

BRACKET

5

205-70-66580

PLATE

6

01010-81240

BOLT

7

01643-31232

WASHER

8

419-09-H2950

UNION

9

42W-09-H2940

CAP

10

419-09-H2780

UNION

11

20E-S95-H290

LUBRICATION PIPE

12

423-00-H1830

ELBOW

13

42W-09-H4520

HOSE

14

205-70-66580

PLATE

15

20E-S95-H140

BRACKET

16

419-09-H2970

ELBOW

17

42W-09-H5000

HOSE

18

42W-09-H4610

HOSE

19

42W-09-H4610

HOSE

20

42W-09-H3730

HOSE

21

42W-09-H5020

HOSE

22

42W-09-H2910

UNION

23

20E-S95-H221

LUBRICATION PIPE

24

20E-S95-H211

LUBRICATION PIPE

25

42W-09-H2910

UNION

26

42W-09-H4530

HOSE

27

42R-09-H1760

COUPLING

28

42W-09-H3220

UNION

29

423-00-H2070

UNION

30

42W-09-H2900

UNION

31

42W-09-H3060

UNION

32

01010-81030

BOLT

33

01643-31032

WASHER

34

20E-S95-H201

BRACKET (WITHOUT AUTO GREASE)

|$36

20E-S95-H430

BRACKET (WITH AUTO GREASE)

35

20E-S95-H230

PLATE (ONLY WITHOUT QUICK COUPLER)

36

01643-31232

WASHER

37

01010-81240

BOLT

Выбрано товаров: 38
