Запчасти Komatsu PW140-7 ОХЛАДИТЕЛЬ ASSEMBLY C СИСТЕМА ОХЛАЖДЕНИЯ

|$1

20E-03-31100

COOLER ASSEMBLY

1

203-03-41410

HOSE

2

205-03-62660

PLUG

3

206-03-43340

CLIP

5

01024-80816

BOLT

6

01024-80835

BOLT

7

01024-81020

BOLT

8

01024-81025

BOLT

9

01024-81030

BOLT

10

01024-81225

BOLT

11

01024-81245

BOLT

12

01434-10616

BOLT WING

13

01597-01009

NUT

15

01643-30623

WASHER

16

01643-31032

WASHER

17

6738-61-4952

COLLAR

18

07000-13045

O-RING

19

07283-34354

CLIP

20

07283-54353

SEAT

21

20E-03-31110

RADIATOR ASSEMBLY

22

20E-03-31131

FRAME LHS

23

20E-03-31141

FRAME RHS

24

20E-03-31151

BASE FRAME

25

20E-03-31161

TOP FRAME

26

20E-03-31171

PLATE

27

20E-03-31182

SHEET

28

20E-03-31190

SHEET

29

22U-03-22860

CUSHION

30

20E-03-31311

NET

31

20E-03-31321

NET

32

20E-03-31341

COVER

33

20E-03-31361

SHEET

34

20E-03-31371

OIL COOLER INLET PIPE

35

20E-03-31381

OIL COOLER OUTLET PIPE

36

20E-03-31390

BRACKET

37

20E-03-31411

BRACKET

38

20E-03-31421

AFTER COOLER

39

20E-03-31451

BRACKET

40

20E-03-31490

SHEET

41

20E-03-31680

PLATE

42

20E-03-31690

PLATE

43

20G-03-31420

PLATE

44

20J-03-11310

SHEET

45

20J-03-11560

HOSE

46

20Y-03-11330

CLIP

47

20Y-03-22110

CAP

48

20Y-03-41580

CUSHION

49

20Y-810-1221

CONDENSER ASSEMBLY

50

20Y-810-1240

BUSH

51

20E-03-31211

OIL COOLER ASSEMBLY
