Запчасти Komatsu PW130ES-6K МОТОР ХОДА (ПЕРЕДН. ВНУТР. ЧАСТИ) (/) СИЛОВАЯ ПЕРЕДАЧА

Схема запчастей Komatsu PW130ES-6K - МОТОР ХОДА (ПЕРЕДН. ВНУТР. ЧАСТИ) (/) СИЛОВАЯ ПЕРЕДАЧА
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40

Артикул

Название

Примечание

Количество

|1

20E-60-K2520

TRAVEL MOTOR ASS'Y,FRONT (FIXED 20 KPH)

|1

20E-60-K2490

TRAVEL MOTOR ASS'Y,FRONT (20 KPH)

|1

20E-60-K2470

TRAVEL MOTOR ASS'Y,FRONT (30 KPH)

1

20G-60-K2630

HOUSING

2

20G-60-K2640

BUSHING

3

20G-60-K2650

PISTON

4

20G-60-K2660

BUSHING

5

20G-60-K2670

BOLT

6

20G-60-K4290

SPRING

7

20G-60-K2690

SPRING

8

20G-60-K4310

O-RING

9

20G-60-K2710

SCREW

10

20G-60-K4320

SCREW

11

20G-60-K2730

RING

12

20G-60-K1490

STUD

13

20G-60-K2740

PIN

14

20G-60-K1520

NUT

15

20G-60-K2750

PIN

16

20G-60-K2760

DISC

17

20G-60-K4330

COVER

18

20G-60-K4340

SCREW

19

20G-60-K4350

SCREW

20

20G-60-K4360

O-RING

21

20G-60-K4320

SCREW

22

20G-60-K4130

VALVE ASS'Y

23

20G-60-K4140

PLATE

24

20G-60-K4150

PISTON

25

20G-60-K4160

TRUNNION

26

20G-60-K4170

RETAINER

27

20G-60-K4180

PIN

28

20G-60-K4190

PLUG

29

20G-60-K2560

SCREW

30

20G-60-K4210

SCREW

31

20G-60-K4220

O-RING

32

20G-60-K4230

O-RING

33

20G-60-K4240

O-RING

34

20G-60-K4250

SCREW

35

20G-60-K4260

RING

36

20G-60-K2580

PIN

37

20G-60-K1270

PIN

38

20G-60-K2590

PIN

39

20G-60-K4280

O-RING

40

20G-60-K3950

SCREW

Выбрано товаров: 43
