Запчасти Komatsu PW130ES-6K ЦИЛИНДР КОВША (ВНУТР. ЧАСТИ) (ДЛЯ ПОВОРОТН. РУКОЯТЬ)(№K87-) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

20E-63-K1231

CYLINDER ASS'Y,BUCKET

1

203-63-75141

CYLINDER

2

707-76-65210

BUSHING

3

07145-00065

SEAL,DUST (KIT)

4

07020-00675

FITTING,GREASE

5

707-27-95921

HEAD,CYLINDER

6

707-52-90420

BUSHING

7

707-51-65030

PACKING,ROD (KIT)

8

707-51-65630

RING,BUFFER (KIT)

9

07000-15085

O-RING (KIT)

10

707-35-90970

RING,BACK-UP (KIT)

11

144-63-92170

SEAL,DUST (KIT)

12

07179-12079

RING,SNAP

13

01010-61465

BOLT

14

705-17-04980

WASHER

15

203-63-75121

ROD

16

707-76-65220

BUSHING

17

707-77-65110

SEAL,DUST (KIT)

18

07020-00675

FITTING,GREASE

19

707-36-95531

PISTON

20

707-44-95180

RING,PISTON (KIT)

21

707-39-95120

RING,WEAR (KIT)

22

707-44-95911

RING

23

01310-01016

SCREW,NYLON

24

707-34-55020

O-RING

25

707-35-90610

RING

26

20E-966-K471

TUBE

27

20E-966-K440

TUBE

28

07000-13025

O-RING (KIT)

29

01010-80850

BOLT

30

01643-50823

WASHER

31

20E-966-K361

BAND

32

20E-966-K380

BRACKET

33

01010-81035

BOLT

34

01643-31032

WASHER

35

07283-22236

CLIP

36

01599-01011

NUT

37

01643-31032

WASHER

38

01010-80835

BOLT
