Запчасти Komatsu PW130ES-6K ЦИЛИНДР РУКОЯТИ(ВНУТР. ЧАСТИ)(№K97-) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

20E-63-K1111

CYLINDER ASS'Y,ARM

1

203-63-65141

CYLINDER

2

707-76-70240

BUSHING

3

07145-00070

SEAL,DUST

4

707-71-32530

COLLAR

5

07000-15105

O-RING

6

707-35-91150

RING,BACK-UP

7

707-27-11971

HEAD,CYLINDER

8

707-52-90500

BUSHING

9

707-51-75030

PACKING,ROD

10

707-51-75630

RING,BUFFER

11

07000-15105

O-RING

12

707-35-91150

RING,BACK-UP

13

144-63-94170

SEAL,DUST

14

07179-13089

RING,SNAP

15

01010-61670

BOLT

16

01643-51645

WASHER

17

203-63-65121

ROD

18

707-71-60200

PLUNGER

19

04260-00635

BALL

20

707-71-91270

CAP

21

707-76-70240

BUSHING

22

07145-00070

SEAL,DUST

23

707-71-60870

PLUNGER

24

07000-15070

O-RING

25

707-36-11661

PISTON

26

707-44-11280

RING,PISTON

27

707-39-11510

RING,WEAR

28

707-44-11920

RING

29

01310-21216

SCREW

30

07000-15070

O-RING

31

707-35-90360

RING

32

203-63-65171

TUBE

33

707-87-13570

ELBOW

34

07000-13025

O-RING

35

01010-80850

BOLT

36

01643-50823

WASHER

37

707-88-95360

BAND

38

707-88-95510

BRACKET

39

01010-81035

BOLT

40

01643-31032

WASHER

41

07283-22236

CLIP

42

01599-01011

NUT

43

01643-31032

WASHER

44

01010-80855

BOLT
