Запчасти Komatsu PW130ES-6K ЦИЛИНДР РУКОЯТИ(ВНУТР. ЧАСТИ)(№K-K97) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

20E-63-K1110

CYLINDER ASS'Y,ARM

1

203-63-64341

CYLINDER

2

707-76-70240

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-71-32510

COLLAR

5

07000-15105

O-RING (KIT)

6

707-35-91150

RING,BACK-UP (KIT)

7

707-27-11670

HEAD,CYLINDER

8

707-52-90500

BUSHING

9

707-51-75030

PACKING,ROD (KIT)

10

707-51-75630

RING,BUFFER (KIT)

11

07000-15100

O-RING (KIT)

12

07001-05110

RING,BACK-UP (KIT)

13

144-63-94170

SEAL,DUST (KIT)

14

07179-13089

RING,SNAP

15

01010-81670

BOLT

16

01643-51645

WASHER

17

203-63-64320

ROD

18

707-71-60200

PLUNGER

19

04260-00635

BALL

20

707-71-91270

CAP

21

707-76-70240

BUSHING

22

07145-00070

SEAL,DUST (KIT)

23

707-71-60830

PLUNGER

24

07000-15070

O-RING

25

707-36-11510

PISTON

26

707-44-11280

RING,PISTON (KIT)

27

707-39-11510

RING,WEAR (KIT)

28

707-44-11920

RING

29

20E-63-K1121

TUBE

30

20E-63-K1131

ELBOW

31

07000-13025

O-RING (KIT)

32

01010-80850

BOLT

33

01643-50823

WASHER

34

707-88-95360

BAND

35

707-88-95510

BRACKET

36

01010-81035

BOLT

37

01643-31032

WASHER

38

07283-22236

CLIP

39

01599-01011

NUT

40

01643-31032

WASHER

41

01010-80835

BOLT
