Запчасти Komatsu PW130ES-6K КАБИНА (ПЕРЕДН. ОКНА)(№K-K999) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

20E-54-K1600

OPERATOR'S CAB ASS'Y

|1

20Y-54-43102

FRONT WINDOW ASS'Y

1

20Y-54-43112

WINDOW

2

20Y-54-38122

GLASS

3

20Y-54-38132

WEATHER STRIP

4

20Y-54-38142

SEAL

5

20Y-54-38152

SEAL

6

20E-54-K6530

LATCH ASS'Y,L.H.

7

20E-54-K6520

LATCH ASS'Y,R.H.

8

01435-30816

BOLT

9

01641-50812

WASHER

10

20Y-54-14290

STOPPER

11

01580-11008

NUT

12

20E-54-K6540

HANDLE

13

01023-10616

SCREW

14

20E-54-K5920

CAP

15

20Y-54-14310

STRIKER

16

20Y-54-14280

SCREW

17

20Y-54-36834

BLOCK,L.H.

18

20Y-54-36844

BLOCK,R.H.

19

01252-50635

BOLT

20

01641-50608

WASHER

21

20E-54-K6550

ROLLER

22

20Y-54-39152

ROLLER

23

205-54-63310

LOCK ASS'Y

24

01435-30820

BOLT

25

20Y-54-39363

BRACKET

26

01435-30820

BOLT

27

01643-50823

WASHER

28

20E-54-K6560

SWITCH

29

01583-11511

NUT

30

20Y-54-39590

WIRING HARNESS

31

20E-54-K6570

GROMMET

32

08051-00801

CLIP

33

20Y-54-14721

LOCK

34

01435-30820

BOLT

35

01643-50823

WASHER

|36

20Y-54-43201

LOWER WINDOW ASS'Y

36

20Y-54-43210

LATCH ASS'Y,L.H.

37

20Y-54-43220

LATCH ASS'Y,R.H.

38

20Y-54-36142

PLATE

39

08037-01610

GROMMET

40

01225-70612

SCREW

41

20Y-54-36211

COVER

42

20Y-54-36113

GLASS

43

20Y-54-36171

SEAT

44

01641-50608

WASHER

45

01370-00620

SCREW
