Запчасти Komatsu PW130-7K ПЕРЕДНИЙ МОСТ (/) (.M ШИР.) SUSPENTION И КОЛЕСА
1
2
3
4
5
5
6
7
8
9
10
10
11
11
12
12
13
13
14
15
15
16
17
18
19
20
20
21
21
22
22
23
24
25
№
Артикул
Название
Примечание
Количество
|1
20G-23-31001
AXLE ASS'Y
1
20G-23-31530
AXLE BEAM,LONG
2
20G-23-31560
AXLE BEAM,SHORT
3
20G-23-31570
SCREW
4
20K-14-32330
PLUG
5
20K-23-32150
PLATE,THRUST
6
20G-22-31280
WASHER
7
20G-23-31610
O-RING
8
20K-22-31270
PLUG
9
20K-23-31680
NIPPLE
|10
20G-23-32180
PIN ASS'Y
10
20G-23-31630
PIN
11
20K-23-31680
NIPPLE
12
20K-23-31310
CAP,PROTECTION
13
20G-23-31640
BUSHING
14
20G-23-31650
RING
15
20G-23-31660
WASHER
16
20G-23-31670
BREATHER
17
20K-23-31580
BUSHING
18
20G-23-31470
RING
19
20G-23-31460
LIP SEAL
20
20G-23-31680
RING,SEAL
21
20G-23-31690
O-RING
22
20K-23-31770
SCREW
23
20G-23-31710
PIN,SPRING
24
20K-23-31790
DOWEL,SECURITY
25
20K-23-31310
CAP,PROTECTION
Выбрано товаров: 27
