Запчасти Komatsu PW130-7K РУЛЕВОЕ КОЛЕСО КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20k-54-31501

COLUMN ASS'Y,STEERING

|1

20K-54-31500

COLUMN ASS'Y,STEERING

|1

20K-54-32561

GAS SPRING

|1

20K-54-32560

GAS SPRING

|1

20K-54-32570

KIT

|1

20K-54-32580

SPRING

2

20G-40-K1250

NUT

3

20E-06-K1240

SWITCH

4

20K-40-31151

BRACKET

5

20K-40-31111

COVER

6

20K-06-31990

SWITCH

7

01023-20510

SCREW

8

20Y-979-6161

SENSOR

9

20K-06-31620

LAMP ASS'Y

10

20E-40-K1260

WHEEL

11

20E-40-K1320

CAP

12

20E-40-K1310

HANDLE

13

01643-31032

WASHER

14

01023-20510

SCREW

15

20K-54-31750

NUT

16

01370-40414

SCREW

17

20J-40-11130

COVER

18

20J-40-11140

COVER

19

20J-40-11121

COVER

|20

20J-06-11142

SWITCH ASS'Y

20

20J-06-31130

SWITCH

21

20J-06-11241

PLATE¤ MARK,PARKING LAMP

22

20J-06-11161

WIRING HARNESS,STEERING

23

20J-40-11190

BRACKET

24

20J-06-11191

LAMP ASS'Y

|24

20J-06-11430

HOLDER

|24

20J-06-11440

LENS

|24

20J-06-11450

LENS

25

01010-81025

BOLT

26

08034-40521

BAND

27

08059-00413

CLIP
