Запчасти Komatsu PW130-7K ОСНОВН. КОНСТРУКЦИЯ (P.P.C. КЛАПАН ШЛАНГИ) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

20E-62-21101

HOSE ASS'Y

1

20E-62-21361

HOSE

|1

21U-62-34760

BAND¤ RED

|1

21U-62-34730

BAND¤ GREEN

|1

20E-62-K7380

MARK¤ P2

2

20E-62-21351

HOSE

|2

21U-62-34750

BAND¤ BLUE

|2

21U-62-34770

BAND¤ WHITE

|2

20G-62-K8750

MARK¤ T

3

20E-62-21340

HOSE

|3

21U-62-34730

BAND¤ GREEN

|3

203-62-57930

MARK¤ 3

4

02760-00227

HOSE

|4

21U-62-34740

BAND¤ ORANGE

|4

203-62-57940

MARK¤ 4

5

02764-00228

HOSE

|5

21U-62-34770

BAND¤ WHITE

|5

203-62-57950

MARK¤ 5

6

02764-00227

HOSE

|6

21U-62-34780

BAND¤ BROWN

|6

203-62-57960

MARK¤ 6

|7

20E-62-21201

HOSE ASS'Y

7

02760-00226

HOSE¤ 2600MM

|7

21U-62-34750

BAND¤ BLUE

|7

203-62-57970

MARK¤ 7

8

02760-00226

HOSE¤ 2600MM

|8

21U-62-34760

BAND¤ RED

|8

203-62-57980

MARK¤ 8

9

02760-00224

HOSE

|9

21U-62-34720

BAND¤ BLACK

|9

203-62-58170

MARK¤ P2

10

02760-00219

HOSE¤ 1900MM

|10

21U-62-34710

BAND¤ YELLOW

|10

203-62-62450

MARK¤ P3

11

20E-62-21371

HOSE

|11

21U-62-34760

BAND¤ RED

|11

21U-62-34730

BAND¤ GREEN

|11

20E-62-K7380

MARK¤ P2

12

20E-62-21490

HOSE

|12

21U-62-34750

BAND¤ BLUE

|12

21U-62-34770

BAND¤ WHITE

|12

20G-62-K8750

MARK¤ T
