Запчасти Komatsu PW130-6K МАРКИРОВКА (ГЕРМАН.) МАРКИРОВКА

1

20E-00-K1170

PLATE¤ CAUTION,WINDOW (R.H.)

2

20E-00-K1230

PLATE¤ CAUTION,REAR WINDOW LOCK BACK

3

20E-00-K1280

PLATE¤ OPERATING,SWING AND PUMP OVERLOAD

4

09685-00001

PLATE¤ OPERATING,LOCK LEVER

5

20E-00-K1410

PLATE¤ OPERATING,CHASSIS ATTACHMENT

6

20G-00-K1461

PLATE¤ OPERATING,SWING LOCK

7

20E-00-K1360

CHART¤ INFORMATION,FUSE

8

20E-00-K1320

PLATE¤ CAUTION,R.H. WINDOW WHEEL

9

20E-00-K1420

PLATE¤ DIRECTION,INDICATOR¤ ARROW

10

20E-00-K1430

PLATE¤ OPERATING,F.N.R. SYMBOL

11

20E-00-K1340

PLATE¤ CAUTION,WARNING

12

20E-00-K1370

TABLE,LIFTING CAPACITY 2P.B.

|12

20E-00-K1390

TABLE,LIFTING CAPACITY 1P.B.

13

20E-00-K1450

PLATE¤ WARNING,DO NOT LIFT

14

20E-00-K1130

PLATE¤ CAUTION,L.H. STAND

15

20Y-00-22450

PLATE¤ MARK,HYDRAUMIND

16

20G-00-K1510

PLATE,MAX. SPEED

17

20G-46-K1680

REFLECTOR,AMBER

|17

01220-30512

SCREW

18

20Y-00-K2220

PLATE,EMERGENCY EXIT

19

20E-00-K1250

PLATE,FUEL TANK

20

20E-00-K1470

PLATE,HOT LIQUID HAZARD (TEXT)

21

20E-00-K1310

PLATE¤ CAUTION,STOP ENGINE WARNING (HOOD)

22

20E-00-K1380

MARK,PW130

23

09690-F0315

PLATE¤ MARK,KOMATSU (CAB DOOR)

24

09690-B0315

PLATE¤ MARK,KOMATSU (TOOL BOX)

25

20E-00-K1110

PLATE¤ CAUTION,FALLING FROM UPPER STRUCTURE

26

154-54-23260

SEAT,ANTI-SLIP

27

203-00-51170

SEAT,ANTI-SLIP

28

20E-00-K1440

SEAT,ANTI-SLIP

29

09696-00100

PLATE,SOUND POWER LEVEL

30

09696-10075

PLATE,SOUND PRESSURE LEVEL

31

09960-01001

PLATE¤ MARK,LIFTING POINT

32

205-00-K1773

PLATE¤ NAME

|32

205-00-K1772

PLATE¤ NAME

|32

205-00-K1771

PLATE¤ NAME

|32

04418-13060

SCREW

33

20G-47-K1690

REFLECTOR,RED

|33

01220-30512

SCREW

34

09690-B0710

PLATE¤ MARK,(COUNTER WEIGHT)

35

20G-00-K1510

PLATE,MAX. SPEED

36

09960-01001

PLATE¤ MARK,LIFTING POINT

37

20E-00-K1260

PLATE¤ MARK,ZEBRA

38

20E-00-K1150

PLATE¤ CAUTION,STAY CLEAR WARNING

39

09690-B0500

PLATE¤ MARK,(BOOM)

40

20G-00-K1170

PLATE¤ CAUTION,ZEBRA¤ L.H.

41

20G-00-K1160

PLATE¤ CAUTION,ZEBRA¤ R.H.

42

20E-00-K1140

PLATE¤ CAUTION,STAY CLEAR WARNING

43

20G-06-K1810

PLATE¤ INSTRUCTION,SIDE MARKER LAMP (NOT SHOWN)

44

20E-00-K1120

PLATE¤ INSTRUCTION,AIR CLEANER SERVICE

45

20E-00-K1190

PLATE¤ CAUTION,HOT OIL/WATER WARNING

46

203-00-31120

PLATE¤ INSTRUCTION,HYDRAULIC OIL LEVEL

47

20E-00-K1290

CHART¤ LUBRICATION,LUBRICATION

48

20E-00-K1210

PLATE¤ CAUTION,ACCUMULATOR WARNING

49

20E-00-K1270

PLATE,HYDRAULIC OIL

50

20E-00-K1470

PLATE,HOT LIQUID HAZARD (TEXT)

51

20E-00-K1480

PLATE¤ CAUTION,ARM ANGLE

52

20Y-00-K2380

PLATE,RECOMMENDED LUBRICANT
