Запчасти Komatsu PW130-6K МОТОР ХОДА¤ ЗАДН. (/) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|1

20E-60-K1123

MOTOR ASS'Y,TRAVEL¤ REAR

|1

20E-60-K1122

MOTOR ASS'Y,TRAVEL¤ REAR

|1

20E-60-K1520

VALVE ASS'Y,CONTROL

1

20E-60-K1940

PLATE,VALVE

2

20E-60-K1950

SLEEVE

3

20E-60-K1960

TRUNNION

4

20E-60-K1970

RING,BACK-UP

5

20G-60-K2550

SCREW

|5

20E-60-K1980

SCREW

6

20E-60-K1990

GASKET

7

20E-60-K2010

PLUG

8

20E-60-K2020

BOLT

9

20E-60-K2030

BUSHING

10

20E-60-K2040

BOLT

11

20E-60-K3590

NUT

|11

20E-60-K2050

NUT

12

20E-60-K1930

STUD

13

20E-60-K2060

O-RING

14

20G-60-K1510

O-RING

|14

20E-60-K2070

O-RING

15

20E-60-K2080

O-RING

16

20E-60-K2090

RING,SEAL

17

20E-60-K2110

RING,SEAL

18

20E-60-K2120

PIN

19

20E-60-K2130

PIN

20

20E-60-K1550

PLUG

|21

20E-60-K1920

COVER ASS'Y,UPPER

21

20E-60-K2340

COVER

22

20E-60-K2350

SLEEVE

23

20E-60-K2330

POPPET

24

20E-60-K2360

VALVE

25

20E-60-K2370

BOLT

26

20E-60-K2380

O-RING

27

20E-60-K2390

PLUG

|28

20E-60-K1910

COVER ASS'Y,LOWER

28

20E-60-K2150

HOUSING

29

20G-60-K2640

BUSHING

|29

20E-60-K2160

BUSHING

30

20E-60-K2170

PISTON

31

20E-60-K2180

BUSHING

32

20E-60-K3370

SCREW

|32

20E-60-K2190

SCREW

33

20G-60-K2680

SPRING

|33

20E-60-K2210

SPRING

34

20E-60-K2220

SPRING

35

20E-60-K2230

O-RING

36

20E-60-K2240

BOLT

37

20G-60-K2720

PLUG

|37

20E-60-K2250

PLUG

38

20G-60-K2730

RING,RETAINER

|38

20E-60-K2260

RING,RETAINER

39

20G-60-K1490

STUD

|39

20E-60-K2270

STUD

40

20E-60-K2740

ROTARY SUB ASS'Y

|40

20E-60-K2280

PIN

41

20G-60-K1520

NUT

|41

20E-60-K2290

NUT

42

20E-60-K2310

PIN

43

20G-60-K2760

DISC,RETAINER

|43

20E-60-K2320

RING,RETAINER

44

20E-60-K2480

PLUG,(NOT SHOWN)

45

20E-60-K2540

PLUG,(NOT SHOWN)
